RY 1500 INS

MAINTENANCE WORKSHOP
VERTICAL BENCHTOP

KEY FEATURES:
• Compact
• Sturdy
• Powerful

CAPACITY:
2wb: 2” max.
4ws: 2” max.
6ws: 2” max.

DIMENSIONS:
750 x 660 x 300 mm
(30 x 26 x 12”)

NET WEIGHT:
70 kg (154 lb)

POWER SUPPLY:
Compressed air (7 bar)

TECHNICAL FEATURES:
Optional tool: for small bore ¼”, ⅜”, ½” shell

Standard-Optional-Hydro-Pneumatic-Pump
Hydro-Pneumatic Pump
DISCLAIMER

We reserve the right to modify our products and/or related services and/or discontinue the manufacture and/or supply of any of the products and/or related services, without notice. This document supersedes all previous versions and previously issued documentation. The only official source of technical crimping parameters regarding our products is our Digital Crimp Tools. Printed copies are uncontrolled therefore, please be sure to use the latest versions of our Ryco Crimp App or Ryco Crimp Web Tool. Don’t mix and match: always use original hoses and fittings. For more information, see our Safety Guide.
