RY 80 HP EVO

MAINTENANCE WORKSHOP
VERTICAL BENCHTOP

KEY FEATURES:
• Compact
• Lightweight
• Easy to use
• Balanced design
• Dual stage pump

CAPACITY*:
2wb: 1” max.
4ws: ½” max.

CRIMP RANGE:
6 – 43 mm (0.236 – 1.693”)

CRIMP FORCE:
80 t

OPENING WITH DIES:
+20 mm (+0.787”)

COMPLETE OPENING:
59 mm (2.323”)

MASTER DIE LENGTH:
56 mm (2.205”)

STANDARD DIES:
16, 18, 20, 22, 24, 27, 30**

DIMENSIONS:
360 x 270 x 390 mm
(14 x 11 x 15”)

PACKAGING:
800 x 600 x 830 mm
(31 x 24 x 33”)

NET WEIGHT:
26 kg (57 lb)

GROSS WEIGHT:
39 kg (86 lb)

TECHNICAL FEATURES:
Hand pump: 5000 psi (double speed)

*Indicative capacities depending on hose and fitting type
** Master-dies used as dies set N°39


Maintenance Kits	Hydro-Pneumatic Pump

DISCLAIMER

We reserve the right to modify our products and/or related services and/or discontinue the manufacture and/or supply of any of the products and/or related services, without notice. This document supersedes all previous versions and previously issued documentation. The only official source of technical crimping parameters regarding our products is our Digital Crimp Tools. Printed copies are uncontrolled therefore, please be sure to use the latest versions of our Ryco Crimp App or Ryco Crimp Web Tool. Don’t mix and match: always use original hoses and fittings. For more information, see our Safety Guide.
